Optris CTi LT Infrared Thermometer
Higher Distance-to-spot size ratio of up to 22:1.
Overview
Features
- -58 to 1922°F temperature range
- 8 µm to 14 µm spectral range
- 115 ms (90% energy) response time
- ± 1% or ± 1.8 °F accuracy
- 3.3 ft standard cable length
- 9.8, 26, and 49ft cable length option
- 10 – 95%, non condensing relative humidity
- 8-30 V DC power supply
- 100 mA maximum current draw
- Stainless steel housing
What's in the Box
- Mounting nut
- 1m high temp. head cable
- Electronic box with LCD display and programming keys
- Quick start guide
- 1.5 m USB-C cable incl. adapter USB-A
Description
The Optris CTi LT Infrared Thermometer features one of the world's smallest infrared sensing heads with an optical resolution of up to 22:1 and a spectral bandwidth of 8 µm to 14µm, ideal for high-emissivity targets even at low temperatures. With a wide temperature range from -58 to 1922°F, these pyrometers excel in non-reflecting object measurement. Their design allows operation up to 356°F without additional cooling, for high-temperature environments. They offer precise non-contact temperature measurement with analog and digital outputs for seamless integration into machinery.
